| Frequency Range | 144 - 146 MHz |
| Free Space Forward Gain | 14.4 dBi |
| Front to Back Ratio | 30 dB |
| 3 dB Horizontal Beam width | 36° For Horizontal Antenna |
| 3 dB Vertical Beam width | 39.6° For Horizontal Antenna |
| G/T | tbd. |
| Polarization | With two same cables Horizontal* |
| Distance Between Dipoles | 520 mm |
| Degrees | 90° |
| Isolation Between Antennas (Coupling) | More than 30 dB |
| Nominal Input Impedance | 50 Ohms |
| SWR Across Entire Band | < 1.2 |
| Maximum Power Input | 1000 W for both antennas (1000 W per Antenna) |
| Matching Method | Direct feed through common mode Baluns |
| Connectors | 2 x "N" |
| Number of elements | 20 (10 + 10) |
| Longest element | 1050 mm |
| Element Mounting Position | On Both Sides |
| Boom Length | 5.47 m |
| Single Antenna Length | 4.91 m |
| Boom Size | Tapered Boom 40 x 40 mm + 30 x 30 mm |
| Number of Boom Pieces | 4 |
| Guy rope support | Not Necessary |
| Mounting Mast Diameter | 43 - 70 mm 1-1/4" - 2-3/4" |
| Survival Wind Speed | 150 km/h |
| Transportation Length | 1.49 m |
| Antenna Weight | 9.6 kg |
